MEASUREMAN 2-1/2" Dial Size, Glycerin Filled Plumbing Pressure Gauge, 0-100psi, Stainless Steel Case, 1/4" NPT Back Mount

Description This oil filled pressure gauge is designed for media which is not corrosive to brass, also where vibration and pulsation is a concern, typical use for plumbing, gardening, agriculature etc Dial size: 2-1/2"" Process connection: 1/4""NPT lower mount Case: 304 stainless steel case and crimped ring Window: Polycarbonate Dial plate: aluminum, with pointer stop Pointer: Aluminum, black, DIN style Bourdon tube: Copper alloy Movement: Brass Connection: Brass, two piece design Oil cap: rubber, gray color Filling: Glycerin filled, dampens the effect of vibration and pulsation; lubricates the movement and extends the life of gauge. IP class: IP67 Accuracy: +/-3-2-3% Range: 0-100psi single scale Working temperature:-4 to 140 deg F/-20 to 60 deg C Ambient temperature:140 deg F/60 deg C maximum" Measureman has 20 years rich experience in the measuring of pressure, temperature, flow, level industries, The "Measureman" branded products are the combination of continuous good quality and affordable price. "Measureman" products are selected and designed by professional engineers.

• For pressure measuring of gas, liquid which is not corrosive to brass, also where vibration and pulsation is a concern.
• 2-1/2" dial size, 1/4"NPT Lower mount
• Pressure range: 0-100psi single scale, big letters, easy to read
• Stainless steel case, brass wetted parts, glycerin filled
• Accuracy: +/-3-2-3%
