25EWRS550 Watt/VAR 2 1/2 Element +/-1mA Output Transducer 1500 Fullscale Calibrating Watts VARS with Calibration Certificate
Product details
| Management number | 211049785 | Release Date | 2026/04/04 | List Price | $36.00 | Model Number | 211049785 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The EWRS500 Series combines the features of both a Watt and VAR transducer in a single package. The input voltage and current are shared by the Watt and VAR transducer, with an option of specifying separate, isolated or common ground outputs. The result is a package that replaces both a Watt and VAR transducer in half the space, half the installation cost, and half the power consumption. TransData provides high accuracy, electric utility grade transducers sold at over 2000 utilities worldwide. Contact TransData for a wide variety of additional models with available external power and output options.
- 2 1/2 Element, 3-phase, 4-wire Watts VARS self powered Common Ground Outputs [(2) 7-Pin Terminals]
- Accuracy 0.25% of rated output
- +/-1mA output is standard, consult factory for all others
- 5 year factory warranty/Huge in stock inventory
- Retrofit replacement for Scientific Columbus XLWV31K521/2A4
| Item Weight | 3.2 pounds |
|---|---|
| Manufacturer | TransData |
| Product Dimensions | 3.72 x 5.25 x 6.2 inches |
| Is Discontinued By Manufacturer | No |
