NIBCO T-585HP-LF-LL 3/4" Threaded Full Port Ball Valve W/Locking Handle
Product details
| Management number | 211105331 | Release Date | 2026/04/04 | List Price | $13.04 | Model Number | 211105331 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The 585HP is on the cutting edge of manufacturing technology, ease of installation, and highest quality standards. The Classic Ball Valve has been completely rethought and redesigned to enhance the user experience and incorporate advances in assembly technology. NIBCO has created the most advanced commercial ball valve on the market today. The valve is laser-welded to create an incredibly strong joint between the body and body-end pieces, eliminating a potential leak path. The weld allows for an increased pressure rating of 1,000 psi, up from the standard 600 psi.
- Valve pressure rating 1,000 psi 69 bar non-shock cold working pressure
- 150 psi/10 Bar Steam Working Pressure
- Maximum temperature rating 300°F
- Full port
- Laser Welded
| UPC | 039923424303 |
|---|---|
| Size | 3/4 in. |
| Brand Name | NIBCO |
| Unit Count | 1.0 Count |
| Valve Type | Ball Valve |
| Item Weight | 1.16 Pounds |
| Manufacturer | NIBCO INC. |
| Model Number | T585HPLFLL34 |
| Material Type | Bronze |
| Item Type Name | Threaded Ball Valve |
| Exterior Finish | Bronze |
| Item Dimensions | 6.65 x 3.17 x 2.14 inches |
| Number of Ports | 2 |
| Maximum Pressure | 1000 Pound per Square Inch |
| Specification Met | Conforms to MSS SP-145, IAPMO/ANSI Z1157, ICC-ES PMG-1558, NSF/ANSI/CAN-372, NSF/ANSI/CAN-61 |
| Included Components | Valve |
| Inlet Connection Size | 0.75 Inches |
| Inlet Connection Type | Threaded |
| Outlet Connection Size | 0.75 Inches |
| Outlet Connection Type | Threaded |
