Digital Gauss Meter Tesla Meter Fluxmeter Surface Magnetic Field Tester BST-100

BST100 is the first hand-held type Gauss meter of BST series Gauss meters. This instrument is a magnetic field measuring device specially designed for field measurement. Its design concept of lightness, practicality, and portability has been determined at the beginning of instrument design, and its unique method of micro power consumption allows its battery life to be greatly improved.Main technical index Range: 0.1mt-2000mt Unit: mt Accuracy: 0.1mt/1mt Measured magnetic field: DC magnetic field Peak lock: None Polar Display: None Supply voltage: DC 9V laminated cell Display meter: 3 1/2 digital display Measurement scope:0～200mT～2000mT(1mT=10Gs) Accuracy: 1% Resolution: 0.1mT Temperature error: -0.06%/°C Operating environment: Temp.: -10°C～40°C Humidity: 35～75% Size:131mm*66mm*26mmMain application areas: The surface magnetic field of permanent magnetic materials. The magnetic field within the structure of the gap Generated by permanent magnets used in the magnetic field, ferromagnetic materials absorb the magnetic field generated by the equipment (such as the separator, magnetic separator, permanent magnetic chuck, electromagnetic, etc.) Ferromagnetic material remaining weak magnetic field magnetic field

• With a small volume, lightweight, and convenient carry, this instrument can meet the measurement requirements of various sites.
• Adopt micro power consumption design. With extended service life, the battery can be continuously used for more than 10 hours;
• You can select a transverse probe or axial probe.
• Have judgment function of magnetic field polarity.
