PTFE Coated Glass Fabric Tape 6 Mil (78106) (3/4" (19.0mm) x 36Yd-1 Roll Per Case, Brown, with Liner)

** PTFE Coated Glass Fabric Tape 36 Yards, Brown, PTFE impregnated fiberglass cloth, consisting of warp and fill yarns, and coated with a high temperature silicone adhesive. Excellent electrical, mechanical and chemical properties. Used as a primary insulation in a variety of electrical equipment and heat sealing bars, chute liners, gaskets, bearing surfaces, tabletop covers, guide rails and roll covers. Low friction surface; abrasion resistant. Product comes standard with liner. Self-wound is optional at no additional cost. PTFE coated glass fabrics (without adhesive) are also available. Roll size of “NA”: 37-1/2” wide x 36 yd or 18 yd lengths. Call for pricing. 1/2” AND 3/4” WIDE ROLLS MUST BE SELF WOUND. Operating temperature range: -100°F to +500°F (-73°C to +260°C). 3” plastic core. Physical Properties: Backing 5.4 mil/0.0054” Total thickness 0.0084” Breaking strength, Warp/fill (lb/in) 150/140 Peel strength (oz/in) 40 Elongation, Warp/fill 3.0%/4.0% Electrical strength (total volts) 6500 Alternative to 3M #5453; DeWal #134-6; St. Gobain #SG25-06; Greenbelt #100-6S; W.F. Lake #L-40S-6; Taconic #6085-06; Chemfab #350-6S; Lanmar #635-6; AFC #25006S Note: The physical properties listed above are typical test results obtained from a series of laboratory tests and should not be used for the purpose of writing specifications. Before using this product, user shall determine the suitability of the product for his/her use; and user assumes all risks and liabilities in connection therewith. All test procedures used are in accordance with ASTM and PSTC methods.

• PTFE Coated Glass Fabric Tape 6 Mil
• 3/4" (19.0mm)[Roll]
• With Liner
